MIL-T-81778C(AS)
11 July 1977
Superseding
MIL-T-81778B(AS)
6 December 1974
MILITARY SPECIFICATION
TEST STATION, LOW FREQUENCY
OJ-215( )/AWM-23(V) and OJ-379( )/AWM-23(V)
This specification has been approved by the Naval
Air Systems Command, Department of the Navy
1.
SCOPE
1.1 Scope. This specification covers the performance, design, and test
requirements for the Low Frequency Test Station (LFTS) OJ-215( )/AWM-23(V)
and OJ-379( )/AWM-23(V) (see 6.9).
1.2 Classification. The LFTS consists of a 3-bay station, an antenna mount-
ing stand, and accessories as follows (see 6.4):
a.
Bay No. 1: Console, Test, Low Frequency, Receiver-hpllfier
OJ-253( )/AWM-23(V).
Reference
Paragraph
Nomenclature
3.6.1.1
Panel, Power Distribution
SB-3696( )/AWM-23(V)
3.6.1.2
Counter/Timer
3.6.1.3
Digital Multimeter
3.6.1.4
Monitor, Coordinate Data
ID-1861( )/AWM-23(V)
Frequency Response Analyzer
3.6.1.5
3.6.1.6
Panel, Coolant Supply
MX-9307( )/AWM-23(V)
3,6.1.7
Mounting MT-4502( )/AWM-23(V)
3.6.1.8
Power Supply PP-6850( )/AWM-23(V)
Power Supply, DC
3.6.1.9
3.6.1.10
Distribution Box
J-3110( )/AWM-23(V)
