MIL-T-85027(AS)
10 October 1975
MILITARY SPECIFICATION
TEST SET, ANTENNA, BORESIGHT
TS-3568( )/AWM-23 (V)
This specification has been approved by the Naval
Air Systems Command, Department of the Navy
1.
SCOPE
This specification covers the
1.1 Scope.
performance, design and test requirements for the Antenna
Boresight Test Set (ABTS) TS-3568( )/AWM-23(V).
1.2 Classification.
The ABTS consists of the
following items:
Reference
Paragraph
Nomenclature
Boresight fixture, antenna (array)
a.
3.6.1
b.
Boresight fixture, antenna (base)
3.6.2
Spindle Mirror
3.6.3
c.
Autocollimator
3.6.4
d.
Zero pins (two each)
e.
3.6.5
Array support positioning plate
f.
3.6.6
Storage case
3.6.7
g.
2.
APPLICABLE
DOCUMENTS
2.1 General.
The following documents, of the issue
specified in AS-4053, Applicable Document List for Airborne
Weapon Control System (AWCS) Test Set AN/AWM-23(V), form a
part of this specification to the extent specified herein.
MIL-T-81734 (AS) is the applicable general specification for
the set described herein (see 6.6).
1
