MIL-D-85859(AS)
Test point, TP21, shall be provided to check if
3.5.1.7 ANT SELECT, TP21.
aft antenna is selected.
3.5.1.8 MSB-2, TP17. Test point, TP17, shall be provided for monitoring
the Phase Data Link recognition code output of channel select BIT display
board when testing XMTR power supply assembly.
3.5.1.9 MSB, TP22. Test point, TP22, shall be provided for monitoring the
output of the one wire channel select decoder.
3.5.1.10 MSB+2, TP18. Test point, TP18, shall be provided for monitoring
the Phase Data Link recognition code output of channel select BIT display
board when testing XMTR power supply assembly.
3.5.1.11 LSB+1, TP23. Test point, TP23, shall be provided for monitoring
the output of the one wire channel select decoder.
3.5.1.12 MSB+, TP19. Test point, TP19, shall be provided for monitoring
the Phase Data Link recognition code output of channel select BIT display
board when testing XMTR power supply assembly.
3.5.1.13 LSB one wire, TP24. Test point, TP24, shall be provided for
monitoring the output of the one wire channel select decoder.
3.5.1.14 LSB, TP20. Test point, TP20, shall be provided for monitoring the
Phase Data Link recognition code output of channel select BIT display board
when testing XMTR power supply assembly.
400 Hz toggle switch, CB1. Toggle switch, CB1, shall be
3.5.1.15 115V,
a circuit breaker provided for turning power ON and OFF to the distribution
box.
3.5.1.16 A XMTR, DS12; B XMTR, DS13; C XMTR, DS14; D XMTR, DS15; E XMTR,
DS16.
Light emitting diodes DS12 through DS16 shall be provided to indicate
the transmitter channel selected in the transmitter power supply.
3.5.1.17 A RCVR, DS17; B RCVR, DS18; C RCVR, DS19; D RCVR, DS20; E RCVR,
DS21. Light emitting diodes DS17 through DS21 shall be provided to indicate
the receiver channel selected in the transmitter power supply.
3.5.1.18 CODE, S13. Switch, S13, shall be provided to set the recognition
code for testing signal-control-processor (SCP).
3.5.1.19 1 WIRE/3 WIRE toggle switch, S11 and switch S14. Toggle switch,
S11, and switch S14 shall be provided to select either one wire or three
wire operation.
3.5.1.20 RECORDER REMOTE toggle switch, S2. Toggle switch, S2, shall be
provided to control +28 volts to video tape recorder.
3.5.1.21 TRIGGER toggle switch, S3. Toggle switch, S3, shall be provided
for an ON/OFF switch to control +28 volts to the AN/AWW-12 or AN/AWW-9
Control-Monitor Set or the SCP.
11
