MIL-D-85859(AS)
3.5.1.55 COCKPIT VIDEO, J11. Connector, J11, shall be provided for
monitoring the video output of the SCP.
3.5.1.56 XMTR MOD, J12. Connector, J12, shall be provided for applying
external modulation to the transmitter.
3.5.1.57 Connector, J16. Connector, J16, shall be provided for connecting
the distribution box to the transmitter power supply.
3.5.1.58 GRD, TP14. Test point, TP14, shall be provided as a common ground
for all test points.
3.5.1.59 NEUTRAL, TP13. Test point, TP13, shall be provided as a common
ground for ac test points.
3.5.1.60
TP12.
Test point, TP12, shall be provided for checking
transmitter 115 Vac
from the SCP.
3.5.1.61
TP11. Test point, TP11, shall be provided for checking
transmitter 115 Vac
from the SCP.
TP10. Test point, TP10, shall be provided for checking
3.5.1.62
transmitter 115 Vac
from the SCP.
3.5.1.63
TP9. Test point, TP9, shall be provided for checking
transmitter 115 Vac
from the SCP.
TP7. Test point, TP7, shall be provided for checking
3.5.1.65
transmitter 115 Vac
from the SCP.
3.5.1.66 BIT +28V, TP6. Test point, TP6, shall be provided for monitoring
+28 Vdc during bit testing.
Test point, TP5, shall be provided for monitoring -12
3.5.1.67 -12V, TP5.
Vdc from the SCP.
Test point, TP4, shall be provided for monitoring -6
3.5.1.68 -6V, TP4.
Vdc from the SCP.
Test point, TP3, shall be provided for monitoring +5
3.5.1.69 +5V, TP3.
Vdc from the SCP.
Test point, TP2, shall be provided for monitoring +12
3.5.1.70 +12V, TP2.
Vdc from the SCP.
Test point, TP1, shall be provided for monitoring +28
3.5.1.71 +28V, TP1.
Vdc from the SCP.
3.5.1.72 Circuit board Al, circuit board A2, and oscillator Y1. Circuit
board Al, circuit board A2, and oscillator Y1, shall provide the capability
to test the one wire channel select function of the SCP or the one wire
demodulator in the AN/AWW-12 or AN/AWW-9 Control-Monitor Set.
14
