MIL-D-85859(AS)
3.6 Detail requirements.
3.6.1 Front panel assembly. The front panel assembly shall contain all the
controls, indicators, and power supply input terminals. The front panel
assembly shall be manufactured in accordance with Drawing 1036AS2018.
3.6.2 Case assembly. The case assembly shall consist of the case on which
shall be mounted connectors, conduit box connector, conduit coupling locknut,
cable strap mount, and rubber feet. The case assembly shall be manufactured
in accordance with Drawing 1036AS2021.
3.6.3 Card holder assembly. The card holder assembly shall contain two
circuit card assemblies. The card holder shall be manufactured in accordance
with Drawing 1036AS510. The two circuit card assemblies shall be manufactured
in accordance with Drawings 1036AS501 and 1036AS505.
3.6.4 Terminal board assembly. The terminal board assembly shall be
manufactured in accordance with Drawing 1036AS2012.
3.6.5 Case, cable storage. The cable storage case shall be manufactured in
accordance with Drawing 1036AS2015.
3.6.6 Power cable assembly, W1. The W1 power cable assembly shall connect
the distribution box to 115V, 400 Hz
power source which in turn
distributes the power to the unit under test. The power cable assembly
shall be manufactured in accordance with Drawing 1036AS112.
3.6.7 Cable, W2. Cable, W2, shall connect the distribution box to the
AN/AWW-12 or AN/AWW-9 Control-Monitor Set when checking the Control-monitor
Set as a system.
3.6.8 Cable assembly, W3, receiver-VTR AN/AWW-12. The W3 cable assembly
shall connect operating voltage and signal input/output between the
distribution box and the video tape recorder, supply three-phase power and
channel selection to the receiver. The W3 cable assembly shall be
manufactured in accordance with Drawing 1036AS2003.
3.6.9 Cable assembly, W4, signal control processor AN/AWW-12. The W4 cable
assembly shall connect operating voltages and signal input/output between
the distribution box and the AN/AWW-12 Signal Control Processor. The W4
cable assembly shall be manufactured in accordance with Drawing 1036AS2004.
3.6.10 Cable assembly, W5, transmitter AN/AWW-12. The W5 cable assembly
shall connect operating voltages and signal input/output between the
distribution box and the AN/AWW-12 Transmitter. The W5 cable assembly shall
be manufactured in accordance with Drawing 1036AS2005.
3.6.11 Cable assembly, W6, receiver-VCTR, AN/AWW-9. The W6 cable assembly
shall connect operating voltages and signal input/output to the video
cassette tape recorder and shall supply the one-wire demodulator, channel
selection, and three-phase power to the receiver. The W6 cable assembly
shall be manufactured in accordance with Drawing 1036AS2006.
3.6.12 Cable assembly, W7, signal control processor, AN/AWW-9. The W7
cable assembly shall connect operating voltages and signal input/output
between the distribution box and the AN/AWW-9 Signal Control Processor. The
W7 cable assembly shall be manufactured in accordance with Drawing 1036AS2007.
that
